炭化タングステン Fastener Die Blanks for Cold Heading Dies
Our R&D engineers combine coarse and fine-grain タングステンカーバイド powders with a high-cobalt formula to produce cold heading dies with improved impact and wear resistance.
It better prevents cracking of cold heading dies, withstands harsher working conditions and improves cold-heading efficiency.
The primary failure mode of fastener dies is cracking, so we have developed impact-resistant carbide for fastener dies.
Advantages
ボルト、ネジ、ナットの成形に適した信頼性の高い超硬工具材料。
Long-life 超硬グレード meeting industry requirements for cold-forming applications.
プレミアムカーバイドによる高い歩留まり。
カスタム公差オプションにより歩留まりが向上します。
Fast delivery: 3-5 days for production, 7-15 days door-to-door shipping.
Air express shipping is available to destinations worldwide.
当社はファスナー成形工具に関して豊富な経験を持ち、耐摩耗性と靱性を向上させた冷間圧造工具用の材料を開発し続けています。 材種 特にステンレス鋼の留め具の形成に適しています。
私たちは、お客様のニーズを満たす製品を提供することに尽力します。
ファスナー成形コア、コーティングされた冷間圧造ダイス、カスタムファスナーダイスなど。
当社材種記号
| トイレの粒度 | 当社材種記号 | Co% | 密度 g/cm3 | 硬度HRA | TRS(MPa) | アプリケーション |
| 中くらい | CG5 | 12 | 14.3 | 88.3 | 3300 | 高靭性冷間圧造金型 |
| CG6 | 14 | 14.12 | 87.3 | 3140 | ||
| 粗い | CA18 | 18 | 13.75 | 85.1 | 2940 | Screw mold with bore below Ø20 |
| CA24 | 24 | 13.25 | 82.5 | 2650 | スクリューモールドΦ20～Φ50 | |
| CT15 | 15 | 13.8 | 86 | 2700 | Stainless steel screw die with bore below <Φ2 | |
| CT20 | 20 | 13.6 | 84.5 | 2660 | Stainless steel screw die with bore above >Ø2 | |
| CA20 | 20 | 13.55 | 84.1 | 2740 | 温間・熱間鍛造金型 |
From Drawing to Delivery
Our standard custom-order workflow for precision carbide components.
PDF / DWG / STEP, with material and quantity
Feedback on pressability, tolerances and grade choice
Unit price, tooling cost and lead time in one sheet
First articles in 7-15 days, inspection report included
You test samples; we adjust grade or geometry if needed
Batch QC on density, hardness and dimensions
Frequently Asked Questions
Which die blank shapes do you supply?
NIB blanks, punch blanks and custom preforms for bolt, nut and screw making machines.
Are blanks supplied sintered or finished?
Sintered blanks for your own finishing, or fully machined die assemblies — both are available.
Which grades suit cold heading?
What is the MOQ and can I order samples first?
There is no fixed MOQ for standard items. Sample orders are welcome so you can verify quality before volume production; shipping is freight collect.
What is the typical lead time?
Standard items are usually shipped in 7–15 days. Custom blanks depend on complexity and are confirmed with the quotation.
